data = FileAttachment("assets/graph_data.json").json()

{
  // ── Sizing ───────────────────────────────────────────────────────────
  const HEIGHT = Math.floor(window.innerHeight * 0.45);
  const PAD    = Math.min(60, width * 0.07);
  const RED    = "#E95420";  // United theme primary

  // Coordinate projection: initial_pos lives in ~[-1.1, 1.1]
  const xSc = d3.scaleLinear().domain([-1.2, 1.2]).range([PAD, width - PAD]);
  const ySc = d3.scaleLinear().domain([-1.2, 1.2]).range([HEIGHT - PAD, PAD]);

  // Edge appearance encodings
  const colorInterp = d3.interpolateRgb("#a0a0a0", RED);
  const opacSc  = d3.scaleLinear().domain([0, 1]).range([0.07, 1.0]);
  const widthSc = d3.scaleLinear().domain([0, 1]).range([0.3, 4.0]);

  // Mutable node positions — seeded from precomputed spring layout,
  // then updated in place by the force simulation in phase 3
  const pos = {};
  for (const [k, [x, y]] of Object.entries(data.initial_pos)) {
    pos[+k] = { x: xSc(x), y: ySc(y) };
  }

  // Force-simulation node objects (positions kept in sync with pos)
  const simNodes = d3.range(9).map(i => ({
    id: i, x: pos[i].x, y: pos[i].y, vx: 0, vy: 0
  }));

  // ── SVG — no background, inherits page colour ─────────────────────────
  const svg = d3.create("svg")
    .attr("width",  "100%")
    .attr("height", HEIGHT)
    .style("display", "block");

  // Edge layer
  const lines = svg.append("g")
    .selectAll("line")
    .data(data.edges)
    .join("line")
      .attr("x1", d => pos[d[0]].x).attr("y1", d => pos[d[0]].y)
      .attr("x2", d => pos[d[1]].x).attr("y2", d => pos[d[1]].y)
      .attr("stroke",         "#a0a0a0")
      .attr("stroke-opacity", 0.07)
      .attr("stroke-width",   0.3)
      .attr("stroke-linecap", "round");

  // Node layer (rendered above edges)
  const circles = svg.append("g")
    .selectAll("circle")
    .data(d3.range(9))
    .join("circle")
      .attr("cx", d => pos[d].x).attr("cy", d => pos[d].y)
      .attr("r",  7)
      .attr("fill",   RED)
      .attr("stroke", "none");

  // ── Force simulation (stopped until phase 3) ──────────────────────────
  const sim = d3.forceSimulation(simNodes)
    .force("charge",  d3.forceManyBody().strength(-200))
    .force("center",  d3.forceCenter(width / 2, HEIGHT / 2))
    .force("collide", d3.forceCollide(22))
    .stop();

  function onTick() {
    simNodes.forEach(n => { pos[n.id].x = n.x; pos[n.id].y = n.y; });
    lines
      .attr("x1", d => pos[d[0]].x).attr("y1", d => pos[d[0]].y)
      .attr("x2", d => pos[d[1]].x).attr("y2", d => pos[d[1]].y);
    circles
      .attr("cx", d => pos[d].x).attr("cy", d => pos[d].y);
  }

  // ── Phase 1 · leapfrog trajectory (100 ms/step × 46 steps ≈ 4 s) ─────
  async function phaseLeapfrog(s) {
    for (let t = 0; t < 23 && alive; t++) {
      const w = data.subpositions[s][t];
      lines.transition("edge").duration(185).ease(d3.easeSinInOut)
        .attr("stroke",         (_, i) => colorInterp(w[i]))
        .attr("stroke-opacity", (_, i) => opacSc(w[i]))
        .attr("stroke-width",   (_, i) => widthSc(w[i]));
      await Promises.delay(100);
    }
  }

  // ── Phase 2 · binomial snap (300 ms transition, 1 s hold) ────────────
  async function phaseSnap(s) {
    const b = data.edge_samples[s];
    lines.transition("edge").duration(300).ease(d3.easeCubicOut)
      .attr("stroke",         (_, i) => b[i] ? RED    : "#a0a0a0")
      .attr("stroke-opacity", (_, i) => b[i] ? 1.0    : 0.05)
      .attr("stroke-width",   (_, i) => b[i] ? 2.5    : 0.2);
    await Promises.delay(1000);
  }

  // ── Phase 3 · force rearrangement (2.5 s) ──────────────────────────────
  async function phaseRearrange(s) {
    const b = data.edge_samples[s];
    const activeLinks = data.edges
      .filter((_, i) => b[i])
      .map(e => ({ source: e[0], target: e[1] }));

    // Seed simulation from current positions; zero velocity
    simNodes.forEach(n => {
      n.x = pos[n.id].x; n.y = pos[n.id].y;
      n.vx = 0; n.vy = 0;
    });

    sim
      .alphaDecay(0.005)
      .velocityDecay(0.6)
      .force("link", d3.forceLink(activeLinks)
        .id(d => d.id)
        .distance(90)
        .strength(0.5))
      .force("wall", () => {
        const margin = 40;
        for (const n of simNodes) {
          // Left wall
          if (n.x < PAD + margin) n.vx += (PAD + margin - n.x) * 0.02;
          // Right wall
          if (n.x > width - PAD - margin) n.vx -= (n.x - (width - PAD - margin)) * 0.02;
          // Top wall
          if (n.y < PAD + margin) n.vy += (PAD + margin - n.y) * 0.02;
          // Bottom wall
          if (n.y > HEIGHT - PAD - margin) n.vy -= (n.y - (HEIGHT - PAD - margin)) * 0.02;}})
      .on("tick", onTick)
      .alpha(0.4)
      .restart();

    await Promises.delay(2500);
    sim.stop();
  }

  // ── Main loop ─────────────────────────────────────────────────────────
  let alive = true;
  invalidation.then(() => { alive = false; sim.stop(); });

  (async () => {
    while (alive) {
      for (let s = 0; s < 25 && alive; s++) {
        await phaseLeapfrog(s);
        await phaseSnap(s);
        await phaseRearrange(s);
        if (alive) await Promises.delay(250);  // 0.25 s before next trajectory
      }
    }
  })();

  return svg.node();
}
